Beam Clamp Extra Wide 3-1/8 in. Jaw With 1/4-20 Threaded Holes From Malleable Iron Electro-Galvanized
SKU
3D-082-501
Beam Clamp Extra Wide 3-1/8 in. Jaw With 1/4-20 Threaded Holes From Malleable Iron Electro-Galvanized is available to buy in increments of 1
Beam Clamp with Extra Wide 3-1/8" Jaw. Tapped and threaded 1/4"-20 holes on both the bottom and back of the clamp. Made from Malleable Iron with an Electro-Galvanized (Zinc Plating)
Beam Clamp Extra Wide 3-1/8 in. Jaw With 1/4-20 Threaded Holes From Malleable Iron Electro-Galvanized
This Extra Wide Mouth Beam Clamp is the ideal choice when you to need to suspended loads off an extra-thick beam or joist. Tapped for rods or fasteners on both the bottom and back of the clamp with 1/4-20 threaded holes. These Malleable iron beam clamps with extra wide 3-1/8" jaw openings allow you to connect almost every wide beam flange or bar joist
Product Attributes
- SKU3D-082-501
- Compatible Rod Size1/4"-20
- DimensionsExtra wide 3-1/8 in. Jaw Opening for Large Beams
- MaterialMalleable Iron
- Surface TreatmentElectro-Galvanized / Zinc
- Holes2 - Bottom and Back
- Load Capacity200 lbs.
| Old Part# | 3D-082-501 |
|---|---|
| Clamp Type | Extra wide 3-1/8 in. Jaw Opening |
| Material/Finish (Mtrl/Fin) | Malleable Iron Electro-Galvanized (Zinc Plated) |
| Max Recommended Load | 200 |
| Rod Size | 00.250 (1/4-20 ) |
| Dimension | Extra wide 3-1/8 in. Jaw Opening for Large Beams |
